5/32 4.0mm Red Dual Wall Adhesive-Lined Heat Shrink Polyolefin Tubing
Adhesive lined heat shrink tubing with environmental sealing capability for a wide variety of electrical applications, including automotive and marine wire harness, wire splices, breakouts, and connector-to-cable transitions.
Features
• 4:1 shrink ratio
• Low longitudinal shrinkage
• Superior sealing against water, moisture or other contaminants
• Ideal for connector sealing covering large diameter differences
• Inner adhesive bonds to plastics, steel and polyethylene
• Flame retardant( out jacket only)
• Continuous operating temperature:-45°C-125°C
Fully shrink temperature:^125°C
Dimensions
| Size | Expanded | After Recovery | Standard Package |
| Inch | mm | Internal Diameter mm | Internal Diameter mm | Total Wall Thickness mm | Adhesive Thickness mm | Spool Length M/spool |
| 5/32 | 4.0 | 4.0 | 1.0 | 1.05±0.30 | 0.50±0.30 | 200 |
| 1/4 | 6.0 | 6.0 | 1.5 | 1.15±0.30 | 0.50±0.30 | 100 |
| 5/16 | 8.0 | 8.0 | 2.0 | 1.5510.30 | 0.60±0.30 | 50 |
| 1/2 | 12.0 | 12.0 | 3.0 | 1.75±0.30 | 0.60±0.30 | 1.22OR25M/Roll |
| 5/8 | 16.0 | 16.0 | 4.0 | 2.00±0.30 | 0.70±0.30 | 1.22OR25M/Roll |
| 25/32 | 20.0 | 20.0 | 5.0 | 2.30±0.40 | 0.70±0.30 | 1.22OR25M/Roll |
| 1 | 24.0 | 24.0 | 6.0 | 2.60±0.40 | 0.75±0.30 | 1.22OR25M/Roll |
| 1-1/4 | 32.0 | 32.0 | 8.0 | 3.00±0.40 | 0.90±0.30 | 1.22OR25M/Roll |
| 2 | 52.0 | 52.0 | 13.0 | 3.35±0.50 | 0.95±0.30 | 1.22OR25M/Roll |
Technical Data
| I Property | Test Method | Standard | Typical Performance I |
| Tensile Strength(MPa) | ASTM D2671 | "10.4 | 11.5 |
| Elongation(%) | ASTM D2671 | N300 | 450 |
| Tensile Strength after aging (MPa) | UI224 158°CX168hr | N7.3 | 8.5 |
| Elongation after aging(%) | UI224 158°CX168hr | N200 | 350 |
| Flammability | ASTM D2671B | Self-extinguish within 30s | Self-extinguish within 30s |
| Dieletric strength(kV/mm) | IEC 60243 | N15 | 17.5 |
| Volume resistivity(Q.cm) | IEC 60093 | ^1X1014 | 2.5X1014 |
Hot Melt Adhesive Property
| Property | Test Method | Standard I |
| Water Absorption | ASTM D570 | <0.2% |
| Sofening Point(°C) | ASTM E28 | 90±5 |
| Strength of pearing(PE) | ASTM D 1000 | 120N/25mm |
| Strength of pearing(AL) | ASTM D 1000 | 80N/25mm |
